Ø 촬상소자 : 1/2.8″ “Exmor”
CMOS
Ø 유효
화소수
: 1920[H]x1080[V] (Approximately
2.38 million pixels)
Ø 출력
비디오 포맷 : 1920x1080p60, 1920x1080i60,
1920x1080p30,
1280x720p60, 1280x720p30,
720x480i59.94(CVBS only),
1920x1080p59.94, 1920x1080i59.94,
1280x720p59.94, 1920x1080p50,
1920x1080i50, 1920x1080p25,
1280x720p50, 1280x720p25,
720x576i50(CVBS only)
Ø 영상출력 : HD/3G-SDI(Level A/B), HDMI, CVBS
Ø 렌즈 : 광학
x20, 디지털
x12
Ø 줌 배율 : 20x Zoom Lens, f=4.7~ 94mm F1.6 ~
F3.5
Ø 수평화각 : 59.5°(W), 3.3°(T)
Ø Tally Led : Red Color
Ø Audio : Stereo Input
Ø IR Input : O
Ø Day & Night : AGC, TDN (ICR)
Ø Focus : Semiauto/ Auto/ Manual
Ø 운전 각도 : Pan: -172˚~
172˚(Non-Endless)
Tilt: total 220˚(-20˚~
0˚~ 180˚~ -160˚)
ØDimensions (millimeters) : 180.6(W)
x 203.0(H) x 197.8(D)mm
Ø Weights : 1.95kg
